Watertight Pin & Sleeve Inlet, 60 A, 250V AC, Single Phase, 2 Pole, IEC Grounding, Blue

The HUBBELL IEC Pin and Sleeve Inlet is an electrical inlet rated for 60A and 250V AC, intended for use in industrial environments. Rated for 60A and 250V AC, this single-phase device features a flanged design with screw terminal wire connections, suitable for #8 to #2 AWG conductors. Constructed from Zytel 101 nylon and thermoplastic materials; meets IP67 ingress standards.

Key Features of the HUBBELL IEC Pin and Sleeve Inlet:

• Current/Voltage Rating: 60A, 250V AC single phase


• Ingress Protection: IP67 rated according to IEC 60529


• Body Material: Zytel 101 nylon housing with neoprene gasket


• Cord Size Compatibility: Accepts #8 to #2 AWG wire sizes


• Wire Connection Type: Pressure terminal screws (screw terminals)


• Flange Type & Dimensions: Flanged; face diameter 2.97 in., flange diameter 3.46 in.


• Temperature Range: Rated operating temperature range: -40°C to +75°C


• Grounding Style: IEC grounding configuration


• Switch Rated & Horsepower Rating: Switch rated; maximum supported load: 3 hp


• Standards Compliance: CSA Certified File LR280C; UL Classified/IEC 60309-1/-2; UL Listed File E146032


• Main Features: Gasketed sealing ring per product specifications; raised collar design per product specifications; shrouded design as specified.
